ED7500-12 XXHD

The ED7500 XXHD series is next generation line of rugged and dependable trap haulers. Designed for ease of installation and use we use the highest quality components to assure years of trouble free operation. All models are mounted on a marine-grade cast aluminum backplate which combines superior structural strength and corrosion resistance with minimum weight. Our backplate provides four splitter mounting points and two additional mounting points for an optional fairlead roller.

At the heart of the ED7500 XXHD series is a 3/4HP 3400 RPM 12V DC motor built for use in tough marine environments paired with an extra heavy-duty 30:1 right angle gear reducer capable of pulling up to 250 pounds while drawing approximately 50-65 amps. The ED7500-12 XXHD hauler comes with 12" steel discs boasting a maximum line speed of up to 310 FPM.
